Compatible with: MITSUBISHI (PAJERO)
| Filled | |
|---|---|
| Voltage [V] | 12 |
| Supplementary Article/Supplementary Info 2 | with magnetic clutch |
| Oil Fill Quantity [ml] | 120 |
| Belt Pulley Ø [mm] | 130 |
| Inlet Diameter [mm] | 18,3 |
| Outlet Diameter [mm] | 15,5 |
| Compressor ID | 10S17C |
| Manufacturer Restriction | DENSO |
| Manufacturer Restriction | MITSUBISHI |
| for OE number | 7813A084 |
|---|---|
| Refrigerant | R 134a |
| Compressor Oil | ND-8 |
| Mounting Type | Bolted |
| Quality | DENSO |
| Length [mm] | 229,5 |
| Height [mm] | 128 |
| Weight [g] | 5850 |
| Gross Weight [g] | 6660 |
| Modification | Years | Engine model | kW |
|---|---|---|---|
| MITSUBISHI 7 | |||
| MITSUBISHI PAJERO IV (V8_W, V9_W) 3.2 DI-D 4WD (V98W, V88W) 4M41 140 kW | 2007–2026 | 4M41 | 140 kW |
| MITSUBISHI PAJERO IV Van (V9_, V8_, V8_V) 3.2 DI-D 4M41 118 kW | 2006–2026 | 4M41 | 118 kW |
| MITSUBISHI PAJERO IV Van (V9_, V8_, V8_V) 3.2 TD 4WD (V88V, V98V) 4M41 147 kW | 2010–2026 | 4M41 | 147 kW |
| MITSUBISHI PAJERO IV (V8_W, V9_W) 3.2 DI-D (V88W, V98W) 4M41 118 kW | 2007–2026 | 4M41 | 118 kW |
| MITSUBISHI PAJERO IV (V8_W, V9_W) 3.2 DI-D (V88W, V98W) 4M41 125 kW | 2007–2026 | 4M41 | 125 kW |
| MITSUBISHI PAJERO IV (V8_W, V9_W) 3.2 DI-D 4WD (V98W, V88W) 4M41 147 kW | 2009–2026 | 4M41 | 147 kW |
| MITSUBISHI PAJERO IV Van (V9_, V8_, V8_V) 3.2 DI-D 4WD (V88W, V98W) 4M41 140 kW | 2007–2026 | 4M41 | 140 kW |
|
|
